Routine Maintenance of Laser Cutting Machine Equipment



Circuit Depaneling Machine is precise, so it is necessary to pay attention to maintenance during operation, and usually pay attention to maintenance and maintenance can increase the service life of the equipment, save costs and create greater benefits.
First, the replacement of water and the cleaning of the water tank
The water quality and water temperature of the circulating water directly affect the service life of the laser tube. It is recommended to use pure water and control the water temperature below 35 °C. If it exceeds 35 °C, it is necessary to replace the circulating water, or add ice cubes to the water to lower the water temperature. (It is recommended that the user choose a cooling machine or use two water tanks).
Cleaning the water tank: first turn off the power supply, unplug the water inlet pipe, let the water in the laser tube automatically flow into the water tank, open the water tank, take out the water pump, and remove the dirt on the water pump. Clean the water tank, replace the circulating water, return the water pump to the water tank, insert the water pipe connected to the water pump into the water inlet, and arrange the joints. Power the pump separately and run for 2-3 minutes (fill the laser tube with circulating water).
Second, the fan is clean
The long-term use of the fan will cause a lot of solid dust to accumulate inside the fan, which will cause a lot of noise and is not conducive to exhaust and deodorization. When there is insufficient suction of the fan, the power supply is first turned off, the air inlet pipe and the air outlet pipe on the fan are removed, the dust inside is removed, and then the fan is inverted, and the fan blades are pulled up until it is clean. Then install the fan.
Third, the cleaning of the lens

There are 3 mirrors and 1 focusing mirror on the UV Laser Depaneling Machine (the No. 1 mirror is located at the emission exit of the laser tube, which is the upper left corner of the machine, the No. 2 mirror is located at the left end of the beam, and the No. 3 mirror is located at the laser head. At the top of the part, the focusing mirror is located in an adjustable barrel in the lower part of the laser head. The laser is reflected by these lenses, focused and emitted from the laser head. The lens is easily stained with dust or other contaminants, causing laser loss or lens damage. Do not remove the No. 1 and No. 2 lenses. Just wipe the lens with the cleaning solution carefully along the center of the lens. Edge rotary wipe. The No. 3 lens and the focusing mirror need to be taken out from the frame, and wiped in the same way. After the wiping is completed, it can be put back as it is.
